Axial Cylindrical Roller Bearing

1.Type:Cylindrical roller thrust bearings, Tapered roller thrust bearings, Spherical roller thrust bearings,
screw-down-bearings
2. Sizes： Inner Diameter; 200-380mm
Outer Diameter: 400-670mm Weight: 75-274kg
3. Feature:Cylindrical roller thrust bearings are separable. They only carry axial loads in one direction and slight shock loads, but their loading capacity is much higher than thrust ball bearings with same dimensions. They can limit axial displacement of shafts or housing in one direction, so can be as axial locating bearings in one direction. the slippage will formed on the raceways because of the linear velocity differences of two ends of rollers while rolling. So the Limiting speed of these bearings is lower than thrust ball bearings, and they are usually applied to low speed applications.
Tapered roller thrust bearings can only carry axial loads and limit axial displacement in one direction, so they can be used as axial locating bearings in one direction. Comparing with cylindrical roller thrust bearings, their loading capacity is higher, relative slippage and limiting speed are lower.
4. Cage: Metal machined solid cages are used for cylindrical roller thrust bearings which are standard design, but otehr cages also can be provided according to customers.
Steel or brass cages are used in tapered roller thrust bearings
5. Application:Cylindrical roller thrust bearings mainly used in heavy machine tools, large power gear boxed for ships, oil rigs, vertical machines, etc.
Tapered roller thrust bearing are widely used in construction machinery, automotives, generating equipments, etc.
6. Material: GCr15/GCr15SiMn/G20Cr2Ni4A

Send Inquiry Download

An Axial Cylindrical Roller Bearing is a specialized type of bearing designed to handle axial loads in one direction. Unlike radial bearings, which support loads perpendicular to the shaft, the products are engineered to support loads parallel to the shaft. They are particularly effective in applications where high axial loads are present but radial loads are minimal. These bearings feature cylindrical rollers arranged parallel to the shaft, allowing for high load-carrying capacity and precision.

Why Choose CHG Bearing for Your Axial Cylindrical Roller Bearings?

At CHG Bearing, we are committed to delivering top-notch the product tailored to meet the demands of various industrial applications. Here’s why you should consider us:

Customization and Solutions: We understand that every industrial application is unique. CHG Bearing offers customization options to suit different working conditions, ensuring optimal performance and longevity.
Extensive Experience: With over 30 years in the industry, our expertise is backed by a strong track record of cooperation with major companies across different sectors.
Innovative Technology: Our commitment to innovation is reflected in our portfolio of over 50 invention patents. We adhere to stringent quality standards, holding certifications such as ISO9001 for quality management and ISO14001 for environmental management.

For more information or to discuss your specific needs, feel free to contact us at sale@chg-bearing.com.

Technical Specifications

Specification	Details
Type	Axial Cylindrical Roller Bearing
Material	High-grade Steel
Load Capacity	High Axial Load Capacity
Temperature Range	-20°C to +120°C
Accuracy	High Precision
Dimensions	Customizable
Lubrication	Customizable
Certifications	ISO9001, ISO14001

Benefits of Axial Cylindrical Roller Bearings

High Load Capacity: Designed to handle significant axial loads, these bearings ensure stable operation under heavy loads.
Precision Performance: With high precision, they enhance the accuracy and efficiency of machinery.
Durability: Built to withstand harsh environments, they offer long service life and minimal maintenance.
Customization: Tailor-made solutions ensure that the bearings meet specific operational requirements and conditions.

Applications

Axial Cylindrical Roller Bearing is essential in various industries, including:

Metallurgical Industry: Used in large rotating equipment such as blast furnaces and rolling mills.
Mining Machinery: Ideal for supporting rotation in crushers, screens, and feeders.
Construction Equipment: Found in machinery requiring high axial load support.
Industrial Machinery: Used in various applications where axial load capacity is critical.

Installation Guide

Preparation: Ensure that the shaft and housing are clean and free of debris.
Alignment: Properly align the bearing with the shaft and housing to prevent misalignment issues.
Press Fit: Use appropriate tools to press the bearing into place, ensuring a snug fit.
Lubrication: Apply the recommended lubricant to reduce friction and wear.
Inspection: Check for proper installation and alignment before operating the machinery.

Maintenance and Care

Regular Inspections: Periodically check for signs of wear or damage.
Lubrication: Follow the manufacturer’s guidelines for lubrication intervals and types.
Cleanliness: Keep the bearing and its surroundings clean to prevent contamination.
Alignment Checks: Regularly verify that the bearing remains properly aligned to prevent premature failure.

FAQ

Q: What is the main advantage of Axial Cylindrical Roller Bearings over other types?

A: The primary advantage is their ability to handle high axial loads while providing precision and durability.

Q: Can Axial Cylindrical Roller Bearings be customized?

A: Yes, CHG Bearing offers customization to meet specific application needs, including size, material, and lubrication.

Q: How often should I lubricate the bearings?

A: Lubrication frequency depends on the operating conditions. Follow the manufacturer’s recommendations for optimal performance.

Q: What should I do if I notice unusual noise or vibration?

A: Unusual noise or vibration may indicate a problem. Inspect the bearing for damage or misalignment and address the issue promptly.

Customer Reviews

John D. - Metallurgical Engineer
"The bearing from CHG Bearing has been a game-changer for our production line. Their performance and durability are unmatched!"

Sarah T. - Production Manager
"CHG Bearing’s customization options allowed us to find the perfect solution for our machinery. Highly recommended for their quality and service."

Michael S. - Mining Equipment Dealer
"Excellent bearings with fast delivery times. CHG Bearing’s customer support is top-notch, always ready to assist with our needs."

Contact Us

For more information or to place an order, please contact us:

Email: sale@chg-bearing.com
Website: www.chg-bearing.com

At CHG Bearing, we are dedicated to providing high-quality Axial Cylindrical Roller Bearing that meet your specific needs. Reach out to us today to discover how we can support your industrial applications.
