Roller Thrust Bearing

1.Type:Cylindrical roller thrust bearings, Tapered roller thrust bearings, Spherical roller thrust bearings,
screw-down-bearings
2. Sizes： Inner Diameter; 200-380mm
Outer Diameter: 400-670mm Weight: 75-274kg
3. Feature:Cylindrical roller thrust bearings are separable. They only carry axial loads in one direction and slight shock loads, but their loading capacity is much higher than thrust ball bearings with same dimensions. They can limit axial displacement of shafts or housing in one direction, so can be as axial locating bearings in one direction. the slippage will formed on the raceways because of the linear velocity differences of two ends of rollers while rolling. So the Limiting speed of these bearings is lower than thrust ball bearings, and they are usually applied to low speed applications.
Tapered roller thrust bearings can only carry axial loads and limit axial displacement in one direction, so they can be used as axial locating bearings in one direction. Comparing with cylindrical roller thrust bearings, their loading capacity is higher, relative slippage and limiting speed are lower.
4. Cage: Metal machined solid cages are used for cylindrical roller thrust bearings which are standard design, but otehr cages also can be provided according to customers.
Steel or brass cages are used in tapered roller thrust bearings
5. Application:Cylindrical roller thrust bearings mainly used in heavy machine tools, large power gear boxed for ships, oil rigs, vertical machines, etc.
Tapered roller thrust bearing are widely used in construction machinery, automotives, generating equipments, etc.
6. Material: GCr15/GCr15SiMn/G20Cr2Ni4A

Send Inquiry Download

What is a Roller Thrust Bearing?

A Roller Thrust Bearing is a specialized type of bearing designed to support axial loads in machinery. Unlike standard ball bearings that can handle both radial and axial loads, they are specifically engineered to handle significant axial forces. They are constructed with rolling elements (typically cylindrical or tapered rollers) that facilitate smooth rotation and high load capacity. This makes them essential in various heavy-duty applications, especially in the metallurgical and mining industries where equipment operates under extreme conditions.

CHG Bearing: Your Expert Roller Thrust Bearing Manufacturer

At CHG Bearing, we pride ourselves on being a leading manufacturer and supplier of Roller Thrust Bearings. With over 30 years of experience in the industry, we offer:

Customization and Solutions: We provide tailored solutions for different working conditions, ensuring that our bearings meet the specific needs of your equipment.
Proven Expertise: Our extensive experience includes collaborations with numerous large companies, highlighting our reliability and competence.
Innovative Technology: With more than 50 invention patents, our commitment to innovation is backed by certifications including ISO9001 for quality management and ISO14001 for environmental management.

For more information or to discuss your specific needs, contact us at sale@chg-bearing.com.

Technical Specifications

Specification	Details
Type	Roller Thrust Bearing
Load Capacity	High axial load capacity
Materials	Steel, ceramic, and custom materials
Precision	High precision
Lubrication	Grease or oil-based
Operating Temp.	Up to 200°C
Certifications	ISO9001, ISO14001

Benefits of Roller Thrust Bearings

High Load Capacity: Designed to support heavy axial loads, reducing stress on other components.
Durability: Built to withstand harsh operating conditions, extending the service life of your machinery.
Reduced Maintenance: Low friction and wear resistance minimize the need for frequent maintenance and replacements.
Customization: Ability to tailor bearings to specific requirements, enhancing their performance in specialized applications.

Applications

Roller Thrust Bearings are crucial in various industries and applications, including:

Metallurgical Equipment: Blast furnaces, rolling mills, and steelmaking machinery.
Mining Machinery: Jaw crushers, impact crushers, vibrating screens, and feeders.
Heavy Industrial Equipment: Large rotating machinery requiring high axial load support.

Installation Guide

Preparation: Ensure that the bearing and housing are clean and free from debris.
Alignment: Properly align the bearing with the shaft and housing to prevent premature failure.
Mounting: Use appropriate tools to press the bearing into place, ensuring it is seated correctly.
Lubrication: Apply the recommended lubricant to the bearing to ensure smooth operation.

Maintenance and Care

Regular Inspections: Check for signs of wear or damage periodically.
Lubrication: Maintain proper lubrication levels to avoid friction and overheating.
Cleaning: Keep the bearing and surrounding area clean to prevent contaminants from causing damage.
Alignment Checks: Regularly verify the alignment to avoid uneven wear and potential failures.

FAQ

Q1: What is the primary function of a Roller Thrust Bearing?
A1: They are designed to support axial loads in machinery, providing stability and smooth operation under heavy-duty conditions.

Q3: Can these Bearings be customized?
A3: Yes, at CHG Bearing, we offer customization options to meet specific requirements for various applications.

Q4: What are the typical maintenance needs?
A4: Regular inspections, proper lubrication, and keeping the bearing clean are essential for maintaining performance and extending the service life.
