Single Row Thrust Ball Bearing

1. Details: The thrust ball bearings are classified into two kinds: unidirectional thrust bearing and bidirectional thrust bearing. The former can bear the axial force in one direction and the latter can bear he axial forces in two directions. Both unidirectional and bidirectional thrust ball bearings cannot bear any radial force. Thrust ball bearing can limit axial displacement of shafts or housings in one or two direction, but not radial displacement. Therefore, the bearings are usally used with deep groove ball bearings.
Single direction thrust ball bearing consist of one row of balls ( with cage ), a shaft washer ( close fit with shaft ) and a housing ring ( loose fit with shaft and close fit with bore of bearing block ). They can not carry radial loads but axial loads in one direction, because the axial loads are well distributed on each bal, the loading capacity is higher, but the temperatue is high while working, and their limiting speed is lower.
Double direction angular contact thrust ball bearings are high precision bearings which are specilly designed for spindles of machine toole. They are able to carry axial loads in two directions, and they have more balls with small diameter. The centrifugal influence can be reduced as their 60° contact angle, so more suitable for high speed application.
It can carry axial loads that dimension series 2344 and 2349 double direction angular contact thrust ball bearings fit with dimension series NN30 and NU49 double row cylindrical roller bearings.
Double direction angular contact thrust ball bearings with class SP whose running accuracy is P4 and dimension accuracy is P5 can produced by us.

What is a Single Row Thrust Ball Bearing?

A Single Row Thrust Ball Bearing is a specialized type of bearing designed to handle axial loads, or loads parallel to the axis of the bearing. Unlike other types of bearings that manage both radial and axial forces, this bearing is optimized for handling only axial forces. It's a crucial component in many mechanical systems where support for axial loads is essential.

These bearings consist of a single row of balls arranged between the shaft and the housing. The simplicity of this design makes them ideal for applications where space is limited and axial load support is critical.

Why Choose CHG Bearing for Your Single Row Thrust Ball Bearing Needs?

CHG Bearing is a leading manufacturer and supplier of Single Row Thrust Ball Bearings, known for our:

  • Customization and Solutions: We offer tailored solutions to meet the specific requirements of various working conditions. Whether you need a bearing for high-temperature environments or customized dimensions, we can provide the perfect solution.

  • Experience and Expertise: With over 30 years in the industry, CHG Bearing has established a reputation for excellence. We’ve collaborated with numerous large companies, and our experience ensures that we deliver high-quality products that meet rigorous standards.

  • Innovation and Quality: Our company holds more than 50 invention patents and has achieved ISO9001 and ISO14001 certifications. These certifications reflect our commitment to quality management and environmental responsibility.

For inquiries and customized solutions, contact us at sale@chg-bearing.com.

Technical Specifications

Feature Specification
Type Single Row Thrust Ball Bearing
Load Capacity High axial load capacity
Material High-quality steel or ceramic
Dimensions Customizable according to needs
Operating Temperature Suitable for various temperatures
Certifications ISO9001, ISO14001

Single Row Thrust Ball Bearing and Its Benefits

  • High Load Capacity: Designed to handle significant axial loads, making them suitable for heavy-duty applications.
  • Compact Design: Their single-row design is compact, which is advantageous in applications with limited space.
  • Smooth Operation: The precision balls ensure smooth and efficient operation, reducing friction and wear.
  • Customization Options: We offer bearings tailored to specific needs, including unique dimensions and materials.

Applications

Single Row Thrust Ball Bearings are used in a variety of industries and applications, including:

  • Metallurgical Equipment: Essential for blast furnaces, rolling mills, and other large rotating machinery.
  • Mining Machinery: Found in crushers, screens, and feeders where axial load support is crucial.
  • Industrial Machinery: Utilized in various types of machinery that require reliable axial load support.

Installation Guide

  1. Preparation: Clean the bearing and its housing thoroughly before installation.
  2. Alignment: Ensure proper alignment of the bearing to avoid uneven load distribution.
  3. Assembly: Carefully insert the bearing into its housing, making sure it sits evenly.
  4. Securing: Secure the bearing in place using appropriate tools and methods.

Maintenance and Care

To ensure the longevity of your Single Row Thrust Ball Bearing:

  • Regular Inspection: Check for signs of wear or damage periodically.
  • Proper Lubrication: Keep the bearing lubricated according to the manufacturer’s recommendations.
  • Clean Environment: Protect the bearing from contaminants and harsh conditions that could affect its performance.

FAQ

Q: What makes this bearings different from other bearings?

A: They are designed specifically to handle axial loads, unlike other bearings that manage both radial and axial forces.

Q: Can these bearings be customized?

A: Yes, we offer customization options to meet specific requirements, including dimensions and material choices.

Q: What industries use Single Row Thrust Ball Bearings?

A: These bearings are commonly used in metallurgical equipment, mining machinery, and various industrial applications.

Customer Reviews

“CHG Bearing's have exceeded our expectations. The quality and performance are top-notch, and their customization service is exceptional.” – [Customer Name], [Company]

“The prompt delivery and reliable performance of these bearings have significantly improved our production efficiency. Highly recommended!” – [Customer Name], [Company]

Contact Us

For more information or to place an order, please reach out to us at:

Email: sale@chg-bearing.com
